Continuous Cold 0.9 K and 1.4 K

Supplier :

The cryostat is supplied in two constant-temperature versions: 1.4 K or 0.9 K, each guaranteed to deliver ≥ 100 mW of cooling power at 1.7 K to the experimental plate.

The closed-cycle 4He phase-separator loop holds the plate within ± 5 mK for day-long runs, providing a flat baseline for low-noise transport or detector work

ABOUT

SYSTEM FEATURES

Truly “hands‑off” continuous cooling

Once it reaches base temperature the fridge keeps itself at 0.9 K or 1.4 K indefinitely, so there are no weekly helium fills or sorption‑pump cycles to plan around

Eight‑to‑ten‑hour turn‑around

Room‑temperature to base in a single work‑day, and you’re back at 3 K in under four hours after a sample swap, which keeps high‑throughput test campaigns moving

>100 mW of cooling headroom

Both versions deliver at least 100 mW at 1.7 K, enough to tolerate thick wiring looms, optical windows or small magnets without the plate drifting

Low‑vibration plate architecture

The cold plate is hung on soft copper braids that decouple the pulse‑tube’s motion, keeping mechanical noise down to levels acceptable for qubits, MKID or AFM heads

Touchscreen + remote control + Python API

One‑button cool‑down on the front panel, but also secure web/mobile access and a scripting interface so you can automate thermal cycles from the lab network

Upgradeable path to millikelvin

Order the 0.9 K version and you can bolt in ZPC’s dilution‑insert kit later, pushing the same chassis to ≈10 mK when your experiments need it

PRODUCT

SPECIFICATIONS

MODEL L

Base Temperature < 0.9 K and 1.4 K
Cooling Power 100 mW at 1.7 K
Peak-to-Peak Vibrations < 20nm
Cooldown time < 8-10 hours
Sample size 380 mm diameter 245 mm vertical space
Compact footprint 1.80 m2

MODEL I

Base Temperature < 0.9 K and 1.4 K
Cooling Power 100 mW at 1.7 K
Peak-to-Peak Vibrations < 20nm
Cooldown time < 8-10 hours
Sample size 150 mm diameter 195 mm vertical space
Compact footprint 1.34 m2

OTHER

OPTIONS

Single Axis magnets:
0.5 T to 12 T superconducting, cryogen-free magnets
Vector Magnets:
2-axis and 3-axis vector magnets.
0.5 T to 9 T per axis

Up to five(5) optical windows with direct line-of-sight access to the experiment stage
Maximum diameter: 4 inches / 100 mm
Compatible with cryo-objectives

Actuation pressure:
Tunable. Nominal operation at 5-10 bar Closed-state superfluid leak rate:
Guaranteed: better than 1×10-9 mbar⋅L/s at 1.5 K
Expected: below 1.3×10-10 mbar⋅L/s at 1.5 K

How and Why

Cryogenic System Designs for Quantum Applications

Cryogenic photonic circuits

A continuous 0.9 K bath with optical ports removes the need for a 3He sorption stage during iterative device-foundry runs and lets laser alignment be done through fused-silica windows while the detector stays below its critical temperature

2

Ultra-low-vibration scanning probe microscopy (STM/AFM) near 1 K

ZPC’s braided OFHC heat links and bellows give plate motion in the 10-nm RMS class out of the crate, and an optional pneumatic table brings that below 5 nm for atom-resolved spectroscopy without liquid-helium logistics

3

Muon-spin-rotation and other beam-line sample environments

µSR, neutron, or soft-X-ray instruments often deposit 10–50 mW into the sample platform through photo-heating or eddy-current damping while demanding hours-long constant temperature. A continuous 1 K cryostat with 100 mW overhead can absorb those loads without drifts, and its all-metal vacuum seals survive frequent transport between end-stations

Kinetic-inductance devices and TWPA

TWPAs are typically characterised at 0.8 – 1.2 K, where quasiparticle lifetimes are long enough for high-Q resonances yet the wiring heat load is still manageable. The ZPC 0.9 K version supplies > 100 mW at 1.7 K, so the entire microwave chain (bias tees, isolators, pump lines) can be powered without driving the stage above 1 K, and the sub-5 mK stability keeps gain flat during long calibrations

Rare-earth-ion quantum memories and light–matter interfaces

Narrow homogeneous linewidths (< 100 kHz) and long spin-wave coherence in Yb3+171-doped Y2SiO5 (YSO) and similar crystals improve markedly below ~2 K.
A steady 1 K bath enables 20ms class storage of photonic qubits with minimal spectral diffusion, while optical-access windows in the cryostat let the same sample couple to fibre-coupled cavities or waveguides
